SPECS :
WEIGHT 2.6 KG
MAX. DRILLING CAPACITY (CONCRETE) 26.0 MM
MAX. DRILLING CAPACITY (METAL) 13.0 MM
MAX. DRILLING CAPACITY (WOOD) 30.0 MM
IMPACT ENERGY (EPTA 05/2009) 2.6 J
NO LOAD SPEED 0-1500 RPM
Hand / Arm Vibration - Drilling into concrete 15.4 m / s²
Power Type With Cable
Power 800 W
Bit holder SDS-Plus
Vibration control No
Anti rotation system No
Clutch Yes
Compatible powder solution Yes
Perform and Protect No
Quick change chuck No
Impact drilling mode Yes
Cutting mode Yes
Rotation only mode Yes
Max. Drilling Capacity (Core Drill) 50.0 mm
Height 210.0 mm
Length 335.0 mm
Width 75.0 mm
Uncertainty K 1 (vibration) 1.5 m / s²
Hand / Arm Vibration - Chisel 14.9 m / s²
Uncertainty K 2 (vibration) 1.5 m / s²
Hand / Arm Vibration - Drilling into metal <2.5
Uncertainty K 3 (vibration) 1.5 m / s²
Hand / Arm Vibration - Screwdriving without percussion <2.5
Uncertainty K 4 (vibration) 1.5 m / s²
Sound pressure 89.0 dB (A)
Uncertainty K 1 (sound) 3.8 dB (A)
Acoustic Pressure 100.1 dB (A)
Uncertainty K 2 (sound) 3.8 dB (A)
Impacts per minute 0-5500 ipm
