Grundfos Scala 2 G1 Pressure Group 0.55KW Auroaspirante 98562862

1 / 2

Grundfos Scala 2 G1 Pressure Group 0.55KW Auroaspirante 98562862

Name: Grundfos Scala 2 G1 Pressure Group 0.55KW Auroaspirante 98562862
Brand: Grundfos
SKU: 98562862
Price: 757.92 EUR
Availability: InStock

Brand: Grundfos

Reference: 98562862

Offer: €757.92 (€616.20 Without VAT)

PVP: €1,081.17

Description

Grundfos SCALA2 is a compact, self-priming and fully integrated hydraulic installation for increasing pressure in domestic applications such as houses and apartments for one or two families. SCALA2 incorporates integrated speed control that allows to maintain a perfect pressure in the taps.

Details

More information

SPECS

Technical

Nominal flow 3 m³ / h

Rated head 27 meters

Maximum head 45 m

Head max 45 m

CARBON / CERAMIC primary shaft seal

Approvals CE, VDE, MORO, KC, AAA

Approvals for potable water WRAS, ACS

Curve tolerance ISO9906: 2012 3B

Model A

Materials

Composite pump housing

EPI NORYL FE1630PW + PS-GS30 Pump

Compound Boost

EPI NORYL FE1630PW + PS-GS30

Material code A

Installation

Ambient temperature range 0 .. 55 ° C

Maximum operating pressure 10 bar

Maximum allowable inlet pressure 6 bar

Input connection type R

Output connection type R

Inlet connection size 1 inch

Outlet connection size 1 inch

Pressure rating for PN 10 connection

Liquid

Pumped liquid Water

Liquid temperature range 0 .. 45 ° C

Selected liquid temperature 20 ° C

Density 998.2 kg / m³

Electrical data

Power input - P1 550 W

Network frequency 50/60 Hz

Nominal voltage 1 x 200-240 V

Nominal current 2.8 A

Enclosure class (IEC 34-5) IPX4D

Insulation class (IEC 85) F

Cable length 2 m

Type E / F plug (CEE7 / 7)

Schuko plug

Others

Net weight 9.58 kg

Gross weight 12.2 kg

Shipping volume 0.044 m³

Storage temperature range -40 .. 70 ° C

Reviews

There are no opinions yet Be the first to review!

Questions (2)

Fernando

10/03/2022

Por qual é a razão que no casco de cobertura do Scala 2 abre fissuras de o tamanho de uma cabeça de um alfinete e sai um fiozinho de água com pressão ? Isto é um defeito de fabricaçao ? Em três anos eu já mudei duas vezes de motor e vai no terceiro. Só estou a espera que os técnicos me digam alguma coisa.. Tenho informações de vários clientes que compraram e tiveram o mesmo problema .Será que a fábrica está informada e está a resolver o problema . Eu ainda corro o risco de ter comprado um motor de 500€ € e de repente perder o dinheiro . Eu tenho nas minhas casas de turismo vários motores da Grundfos à mais de 20 anos e funcionam lindamente . Só o Scala 2 é que foi um fiasco. Gostaria que me informa-se se à fábrica com a continuidade de produção já ratificou o defeito e a partir de quando ou o problema continua? Cumprimentos , Fernando Sousa

Store response | 10/03/2022

Fernando, trasladamos tu queja al proveedor.

G.Knegt

29/11/2021

Ik ben op zoek naar de Grundfos Scala 2. P/N 98562862. Hebben jullie deze op voorraad en wat is de prijs ? Met vriendelijke groeten, Gezinus Knegt

Store response | 30/11/2021

Goedemiddag, we hebben voorraad, binnen 5-6 dagen.
