Brand: HISENSE
Reference: CA70BT1A
Split Wall Air Conditioning Set, with silent mode of 21dB. Energy Class A ++ with a compact design. Power 6500 Kw
Brissa 24 Series
Models CA70BT1A
Cooling capacity
Kcal / h 5590 (1376-6192)
W 6500
Heating power
Kcal / h 6106 (1548-6278)
W 7100
Energy saving ratio (SEER / SCOP) Cold / Heat 6.1 / 4.0
Energy class Cold / Heat A ++ / A +
Voltage, frequency, phase 220-240V ~, 50Hz, 1P
Refrigerant Type R32
Refrigerant precharge Kg / tco2eq 1.3 / 0.878
"Additional load 30 g / m"
Sound power level Indoor unit 63 dB (A)
Sound pressure Inner unit
48/45/43/40/39/35 dB (A)
Sound power level Outdoor unit 64 dB (A)
Sound pressure external unit 56 dB (A)
Seasonal annual energy consumption
Fr.o 367 KWh
Heat 1908 KWh
Pipe diameter Liquid - gas 3/8 - 5/8 inch
Measurements
Inner unit 998x325x225 mm
External unit 860x667x310 mm
Net weight
Inner unit 11 kg
Outside unit 48 kg
Operating range
Fr.o -15.C-43.C
Fr.o -15.C-43.C
