Professional clamp meter CA 600A CATIV HT9012, HT-Instruments 1043
Brand: HT-INSTRUMENTS
Reference: 1043
Description
The HT9012 clamp meter is designed for the measurement of AC current up to 600A and AC / DC voltage up to 1000V for the scope of CAT IV 600V and CAT III 1000V in accordance with the IEC / EN61010-1 standard. The clamp is equipped with a large backlit display with 6000 measurement points and an auto-power-off function to preserve battery life.
Details
Features
Maximum clamping diameter 30mm
Display Resolution (Points) 2000
600A current measurement range
AC / DC current 600 ACA
Voltage AC / DC 1000V
Resistance and continuity test with 20MΩ acoustic indicator
Diode test
AC voltage detector
Backlighting
Autorange
Auto power off
Reading hold
MAX
Power supply 1 x 9V type 6F22
CAT IV 600V measurement category
Weight in grams (batteries included) 400
Dimensions (LxWxH) (in mm) 220x76x50
Regulations
EMC 2014/30 / EU
EMC: IEC / EN61326
IEC / EN61010-1
LVD 2014/35 / EU
CE MARKING
