Automatic regulator for ballasts Dali Dinuy RE DMS DA1
Brand: DINUY
Reference: RE DMS DA1
Description
Automatic dimming system, based on natural light, for DALI Luminaires: automatically applies to the luminaires the level of luminosity required to maintain a previously established minimum illumination level, compensating for natural light at all times.
Details
Product reference: RE DMS DA1
Supply Voltage (V): 230VAC
Frequency (Hz): 50/60
Output Channels: 1
Connection terminal type: Elevator
Cable section (mm2): 2.5
· Storage temperature (ºC) (min): -30
· Storage temperature (ºC) (max): 70
Minimum delay (minutes): 10
Maximum timing (minutes): 30
Detection Angle (º): 360
Mounting height (m): 2.5
Detection diameter (m): 7
· Own Consumption: 2W
Type of Load: Reactance or DALI Driver
· Maximum number of extra movement sensors: 14
Brightness level (lux) (min): 100
Brightness level (lux) (max): 1000
· Maximum number of teams: 64
Mounting: Recessed in ceiling
Installation: Recessed in ceiling
· Operating Temperature (ºC) (min): 0
· Operating Temperature (ºC) (max): 40
Environmental Protection: IP20 according to UNE 20324
