CIRCUMAT + 230 V for 360º ceiling, extra flat suitable for LED.IP20 OB137112 Orbis
Brand: ORBIS
Reference: OB137112
Description
CIRCUMAT + ceiling surface installation. Basic functionalities that cover most installations. Equipped with external temperature compensator for more accurate detection. Pulse function: 1 s ON / 9 s OFF. Double neutral terminal for ease of installation.
Details
Power supply: 230 V ac ± 10 %
Nominal frequency: 50/60 Hz
Own consumption: 5.2 VA (0.8 W)
Breaking power: µ 6 A / 230 V~ cosφ = 1
· Detection angle: 360º.
· Detection field: Up to 7 m in diameter at 2.5 m in height. Up to 9 m in diameter at 3 m in height.
· Light sensitivity: 3 to 2000 lux.
· Timing range: 10 s to 30 min. Pulse function 1 s.
Degree of protection: IP20 according to EN 60529.
· Operating temperature: -20 ºC to +40 ºC.
· Operating limit temperature: -20 ºC to +50 ºC.
Maximum loads:
- Incandescent: 1200 W
-Fluorescent: 400 VA
- Low voltage halogen (12 V a.c.): 1000 VA
- Halogen (230 Vac): 1200 W
- Low consumption lamps: 500 VA
- Downlights: 500VA
-LED: 500VA
