MULTIMAT 230 V. Motion detector on wall artic ceiling 200º IP55 OB134212 Orbis
Brand: ORBIS
Reference: OB134212
Description
MULTIMAT motion detector for surface mounting on a wall or ceiling, it can also be installed in corners or corners. IP55 protection against ingress of dust and water jets according to EN 60529. Adjustable parameters: timing and light sensitivity. field limiter. Overrides detection in specific areas of the catchment area. Status LED pilot light that lights up when the equipment detects movement.
Details
Power supply: 230 Vac, 50 Hz
Breaking power: 10 A 230 Vac
Timing: from 3s to 30 min.
Light sensitivity: adjustable 5-2,000 lux
Temp. operation:-20ºC to +40ºC
Degree of protection: IP55 according to EN 60529
Detection angle: 200º
Front detection field: 12 m at 20ºC
Lateral detection field: 8 m at 20ºC
Maximum loads
- Incandescent lamps: 2000 W
- Fluorescent: 1200 VA
- Low voltage halogen: 1200 VA
- Halogens (230V AC): 2000 W
- Low consumption lamps: 1200 VA
- Downlights: 1200VA
- LED lamps: 400 VA
